Display Output

HDMI 2.1 via amdgpu. Works out of the box once amdgpu loads.

Supported Resolutions

Resolution	Refresh Rate	Status
1080p	60 Hz	Working
1080p	120 Hz	Confirmed on ASUS VY249HGR (see note below)
1440p	60 Hz	Working (some monitors have issues)
2160p (4K)	60 Hz	Working (some monitors have issues)
1440p	120 Hz	Confirmed on DELL S3225QC

30 Hz and broader 120 Hz support may be added in the future.

amdgpu.force_1080p=1 caps refresh rate

This flag ships in the default cmdline.txt and was long assumed mandatory, but as of 2026-07-10 testing it isn't required for every monitor and it actively caps output to 60Hz even on displays that support more. Confirmed on an ASUS VY249HGR (native 1920x1080@120Hz, AMD FreeSync 48-120Hz per EDID) — capped to 60Hz with the flag present, full 120Hz once removed. A Lenovo T23d-10 (60Hz-class panel) also displayed fine with the flag removed.

If your monitor won't display at all, it's still worth trying as a troubleshooting step (see below) — but if it does work without it, leave it out, especially on a high-refresh panel.

Confirmed Working Monitors (no cmdline override needed)

• MSI MAG274Q QD E2 (1440p@60)
• DELL S2721DGF (1440p@60)
• DELL U2515H (1440p@60)
• LG 27GL850 (reportedly)
• Lenovo Legion Y27q (reportedly)
• ViewSonic Elite XG270QG (reportedly)
• ASUS VY249HGR (1080p@120, HDMI — needs amdgpu.force_1080p=1 removed for 120Hz, see tip above)
• Lenovo T23d-10 (1080p@60, HDMI)
• Gigabyte M27UP (1440p@60 and 4K@60, both confirmed, HDMI + sound working)
• Samsung Odyssey G50D 27" (1440p@60)
• AOC Q27G4 (needs video=DP-1:... line removed + amdgpu.force_1080p=1 added)
• ASUS TUF Gaming VG289Q (4K@60, sound working)

Confirmed Working TVs

• LG C1 OLED (4K@60)
• LG C2 (4K@60, default cmdline, HDCP on)
• LG C4 48" (4K@60, audio delay is a separate known issue, see Audio)
• TCL 4K 55" (4K@60, wifi/BT also working, kernel 7.1.2+)
• HiSense 58A7100F (4K@60, 1440p@60, 1080p@60 all confirmed)
• Hisense 6Series-55 (4K, needed a TV firmware update first to get past 1080p)
• Xiaomi TV A 50 (2025 model, working)

Same model can still vary

Reports of the exact same TV/monitor model working for one person and black-screening for another aren't uncommon (see Troubleshooting Black Screen above). Panel revision, firmware version, and cable quality all seem to matter. Treat this list as "known to work for someone," not a guarantee.

Troubleshooting Black Screen

Try these in order:

1. Remove video=DP-1:1920x1080@60 from cmdline.txt on the FAT32 partition
2. Add amdgpu.force_1080p=1 to cmdline.txt
3. Toggle HDCP on/off in PS5 settings (try both)
4. Try a different monitor or cable
5. Use an HDMI-to-VGA adapter - confirmed to get some problematic monitors working
6. Try switching TTY: switch to tty2 then back to tty1

Kernel-level fix (advanced): Some users fixed persistent black screens by commenting out specific lines in drivers/ps5/hdmi.c and rebuilding the kernel:

// sceSetBackToUnpluggedSequence();
// sceSetBackToWaitResolutionSequence();
// in the FLAVA3 block: comment out i2c_cmd_4_2() and the sceSetEdid/sceSetWaitPll calls

Rebuild the kernel after making changes - see Kernel Setup.

4K Display - Black Screen After Login

If Linux boots but goes black/blue after the login screen on a 4K display:

1. On PS5 OS go to Settings → Screen and Video → Video Output → set resolution to 4K (not Automatic) and disable 120Hz
2. Add your resolution to cmdline.txt on the FAT32 partition:

   video=HDMI-A-1:3840x2160@60

3. If desktop still doesn't render, SSH in and switch desktop environment - GNOME is confirmed working for some users where other DEs fail

Black Screen Switching to Desktop Mode (SteamOS/Bazzite)

Boots fine into gamemode, but the screen flashes and goes black when switching to desktop mode. dmesg may show:

[drm] Failed to add display topology, DTM TA is not initialized.

SSH in and force the desktop session directly:

steamos-session-select plasma

Confirmed fix on SteamOS/Bazzite installs hitting this. If it persists, try updating to the latest image build first, this has also been reported fixed by newer builds alone.

Link Training Error (Most Common Black Screen Cause)

By far the most common root cause behind reported black screens across many different monitor models. Check dmesg:

amdgpu 0000:20:00.0: [drm] *ERROR* perform_8b_10b_clock_recovery_sequence: Link Training Error, could not get CR after 100 tries. Possibly voltage swing issue

This is fixed by ps5-linux-patches commit fe852d3, confirmed to resolve it, update your kernel to a version that includes it first before trying anything else on this page.

If you're still on an older kernel and can't update immediately, a resolution-toggle workaround can force recovery without a reboot, e.g. with kscreen-doctor (KDE) switch to 1080p then back to your target resolution a few seconds later, this recovers the link without a cold boot on affected setups.

Gamescope Doesn't Recover From Link Training Failure (SteamOS/CachyOS)

If you get white LED (Linux running), SSH works, Steam/gamescope processes are running, but truly no signal on any display (not just black, actually no signal), and dmesg shows the link training error above cycling every ~60-90 seconds: gamescope grabs the DRM device during its initial modeset, hits the link training failure window, and never re-probes even after the PS5's HDMI driver successfully reads EDID afterward (hdmi: got real edid in dmesg). echo detect > /sys/class/drm/card0-DP-1/status does not help, gamescope already holds the device.

No known fix within CachyOS/SteamOS-based images as of this writing. Workaround: switch to an Ubuntu-based image, which handles this correctly out of the box.

Custom EDID Injection

If your monitor's EDID isn't being read/parsed correctly (common on some 4K/ultrawide displays), you can inject a known-good EDID dump manually:

1. Dump your monitor's EDID from another PC (Windows: various free EDID tools; Linux: cat /sys/class/drm/card*/edid while connected)
2. Copy the .bin file to /lib/firmware/edid/my_edid.bin on the Linux partition
3. Add to cmdline.txt:

   drm.edid_firmware=DP-1:edid/my_edid.bin

Note the connector name (DP-1 here) needs to match your actual output, check /sys/class/drm/ for the exact name if unsure.

Black Screen but SSH Works

If you can SSH in but display is black, collect logs to diagnose - see SSH & Getting Help for the full log-dump command. At minimum check:

dmesg | grep -iE 'psp|ucode|firmware'
ls /lib/firmware/amdgpu/

for missing/failed amdgpu firmware, then share the full dump in Discord.

Wayland / X11

Both work. Wayland (sway, weston) recommended.

Audio

See Audio.
